| Brand | Gigabyte |
| Model | Gigabyte B650 EAGLE AX (Wi-Fi 6E) |
| Memory Type | DDR5 |
| Memory MHz | 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 non-ECC Un-buffered DIMM |
| Memory Channel | Dual |
| Memory Slot | 4 |
| Memory Max | 192GB |
| Optane Memory Support | Not Available |
| Chipset Brand | AMD |
| Chipset | AMD B650 |
| Sockets Supported | AM5 |
| Built-in Processor | Not Available |
| Supported CPU | AMD Ryzen 7000 / 8000 Series Processors |
| Generation | Not Applicable |
| Memory Type | DDR5 |
| Memory Slot | 4 |
| Memory Max. | 192GB |
| M.2/SSD Expansion Slot Details | 3 x M.2 Slots (1 x M.2 M key type 25110/22110/2580/2280 support PCIe 5.0/4.0 x4/x2 SSDs, 1 x M.2 M key type 22110/2280 support PCIe 4.0 x2 SSDs, 1 x M.2 M key type 22110/2280 support PCIe 4.0 x4/x2 SSD) |
| Graphics | Integrated |
| Graphics Chipset | Integrated With Processor |
| Multi-GPU Support | Not Available |
| Audio Chipset | Realtek Audio CODEC, High Definition Audio |
| LAN Chipset | Realtek GbE LAN |
| WiFi | Yes |
| Bluetooth | Bluetooth 5.3 |
| USB Port | 1 x USB 3.2 Gen 1 Type-C, 2 x USB 3.2 Gen 2 Type-A, 6 x USB 2.0/1.1 Type-A |
| VGA Port | Not Available |
| DVI Port | Not Available |
| HDMI Port | 1 |
| SATA Port | 4 x SATA |
| Cable Management | Front |
| Heatsink | Not Available |
| RGB Support | ARGB |
| RGB Connector | 3 x addressable RGB Gen2 LED strip headers, 1 x RGB LED strip header |
| Approx. Power Consumption | 70W |
| Form Factor | ATX |
| Supported Operating System | Windows 11/ 10 |
| Body Color | Black |
| Form Factor | ATX |
| Approx_Power_Consumption | 70W |
| Country Of Origin | Taiwan |
| Made in/ Assemble | China |
| Warranty Details | 3 year |
The GIGABYTE B650 EAGLE AX AM5 DDR5 Gaming Motherboard is designed to deliver high-level gaming and professional workloads. The motherboard supports AMD Ryzen 8000/7000 Series processors, making it an excellent choice for high-performance computing. It features four DIMM slots and supports a maximum of 192GB DDR5 memory with speeds of up to 7600 MT/s (OC). Overclocking is enhanced with the support of AMD EXPO and XMP.
As far as storage is concerned, the B650 EAGLE AX features three PCIe M.2 slots with PCIe 5.0/4.0 support for the latest SSDs and four SATA 6Gb/s ports. It also offers RAID 0, RAID 1, and RAID 10 for NVMe and SATA storage devices. The motherboard comes with an integrated AMD Radeon Graphics processor (CPU dependent) and features DisplayPort (3840x2160@144Hz) and HDMI (4096x2160@60Hz) output, making it suitable for high-definition displays. Connectivity is also robust with Realtek GbE LAN (1 Gbps), Realtek Wi-Fi 6E, and Bluetooth 5.3 for seamless networking.
For expansion, it has one PCIe 4.0 x16 slot for graphics cards, in addition to three PCIe 3.0 x1 slots for other devices. Several USB 3.2 Gen 2 and USB Type-C ports are available for additional connectivity, while Realtek HD Audio CODEC delivers 7.1-channel audio for surround sound. The ATX form factor (30.5cm x 24.4cm) allows it to fit in standard cases. Other features like GIGABYTE Control Center (GCC), Q-Flash Plus, and Norton Internet Security (OEM) are also present. This motherboard is an enthusiast-level high-end product for those who wish to upgrade their systems with the newest technology. And it comes with a 3-year warranty
Are you Looking for a reliable Technology Store in Bangladesh? Get the GIGABYTE B650 EAGLE AX AM5 DDR5 Gaming Motherboard from Zettabyte Technologies. We provide 100% Authentic products, the best price, and Home delivery. Purchase from your nearest Zettabyte store or order online from anywhere in Bangladesh. Enjoy peace of mind with our 14-day return policy. Order now and experience the Zettabyte difference.
The current price of the GIGABYTE B650 EAGLE AX AM5 DDR5 Gaming Motherboard is ৳ 25,900. We have a huge collection of GIGABYTE B650 EAGLE AX Products at the best price. Order today before the price increases!
